TruLine TS Soffit

Unique and Durable with the Industry’s Highest Airflow Rating.

Download the Brochure

Soffit That Breathes

TruLine® deep lance ventilation system provides the ideal ventilation when used on both sides of a one-foot overhang. A unique and durable solution with the industry’s highest airflow rating.

Engineered for ultimate ventilation, TruLine is a performance-driven soffit designed to maximize the amount of airflow. Developed using ADT 19 boundary-pushing performance process, TruLine is the most effective aluminum soffit available on the market.

Performance & Design

Ventilation is what TruLine is all about. When you enhance the ventilation, you enhance everything. With TruLine you can reduce the temperature in the attic, prolong the life of your roof and other building materials, reduce energy costs and help improve indoor air quality.

  • 12″ width with 3.375″ panels, 16″ width with 3.375″ panels. Available in 12 ft. length
  • 0.016″ thickness
  • NFA Rating: 16″ width 19.1 NFA full vent, 16″ width 9.9 NFA center vent, 12″ 19.6 NFA full vent, 12″ 5.9 NFA center vent
  • Aluminum soffit available in Full vent, center vent and solid
  • Q800 TuffTech finish
  • Lifetime Limited Warranty

The Benefits of TruLine TS Soffit

Engineered for ultimate ventilation, TruLine is designed to produce the ideal amount of airflow. It’s pretty simple. You want air to enter through your soffit and escape through your roof vent. With proper ventilation, cool, dry air is drawn from the soffit. This prevents hot, moist air buildup, and can reduce the temperature in your attic by as much as 50°F.

  • Maximized Air Flow – Offers more deeper and longer lances per foot
  • Prolongs the life of your shingles & reduces energy costs
  • Thicker paint finish that resists peeling, cracking, chipping or delaminating

TruLine TS Colors

TruLine® TS-Series soffit combines a rich palette of colors meticulously selected for their visual temperatures and deep hues. All colors accent and match today’s most popular siding colors and the TruLine Soffit Accessories.

TruLine TS Colors

509 Norwood

507 Mocha

827 Champagne

807 Clay

511 Terratone

502 Brown

327 Desert Tan

280 White

Explore All Colors
Quality Edge TruLine TS Soffit 511 Terratone


Performance for any project

Building a Healthier Home

When you enhance the ventilation, you enhance everything. With proper ventilation, you can reduce the temperature in the attic, prolong the life of your roof and other building materials, and reduce energy costs.

Ready to Start Your Project?

Our Quality Edge Contractor Network can connect you with multiple qualified and certified contractors within your specified location.


NFA (Net Free Area)
19.6 - 12” Full Vent
19.1 - 16” Full Vent
12.0 - D5 & D6 Full Vent
9.9 - 16” Center Vent
5.9 - 12” Center Vent
Bridge Lances
Q800 TuffTech™
Aluminum 0.019" & 0.016"
Full Vent, Center & Solid

4 Width Options, 12 ft Lengths

Available Options

12″, 0.019″ HP
Solid – S
Center Vent- CV
Full Vent – SV

12″, 0.016″ TS
Solid – S_BLDR
Center Vent – CV_BLDR
Full Vent – SV_BLDR

16″, 0.019″ HP
Solid – 16SS
Center Vent – 16SCV
Full Vent – 16V

16″, 0.016″ TS
Solid – 16SS_BLDR
Center Vent – 16SCV_BLDR

Double 5″, 0.019″
Solid – D5SS
Full Vent – D5VS

Double 6″, 0.019″
Solid – D6SS
Full Vent – D6VS

Building Codes and Best Practices
Proper ventilation [more in-take through soffit than exhaust through roof vents] can lower the attic temperature by as much as 50°F, which significantly reduces the home’s heating and cooling, demands. Ridge and soffit vents help keep the attic space well-ventilated, preventing a build-up of moisture and reducing heat in summer. These vents can prolong the life of the roof.
Typical one foot soffit overhangs should have at least an 11 NFA, so when used on both sides of the home will have a combined NFA of 22 to draw the air flow needed to work with a ridge vent system.


Here are our available resources for more detailed product information.

ARCAT Resources
